Wheeled impact crushers
UV210 VSI impact crusher
- Equipment
- Sandvik CV217 VSI, SA1853 triple deck screen
- Max. feed size
- 700 mm (28 in.)
- Capacity
- Up to 185 mtph (200 stph)
![](/contentassets/b56c74ddb2c04014848e853e25b93fbd/uv312-wheeled-unit-002.jpg?width=480&height=293&rmode=crop&rsampler=bicubic&compand=true&quality=90&v=1686714465&hmac=b7721bd2c77a50c808bc4959957bb8ddfe64c30c231e48b7b4b79547c44b071e)
Sandvik UV210 is a tertiary wheeled crushing unit fully assembled on a single trailer frame. Designed to be highly productive, versatile and mobile to meet your needs, it features a Sandvik CV217 VSI crusher and efficient three deck vibrating screen which is capable of producing 1 - 3 products of premium shape at a low cost per tonne.
Features
-
Ideal for secondary and tertiary crushing
-
High quality, consistently sized output
-
Low cost per tonne
due to electric operation
-
Quick to set-up and easy to maintain
resulting in more uptime and higher productivity
-
Easy access for service and maintenance
Product data
- Equipment
- Sandvik CV217 VSI, SA1853 triple deck screen
- No. of products
- 1-3
- Max. feed size
- 700 mm (28 in.)
- Capacity
- Up to 185 mtph (200 stph)
- Power
- 204 kW (272 hp )
- Transport length
- 12.3 m (40.4 ft)
- Transport width
- 2.8 m (9.2 ft)
- Transport height
- 5.0 m (16.5 ft)
- Weight
- 29,700 kg (65,447 lb*)
Please note all weights and dimensions are for standard units only.
Please note this unit is not available globally.
Additional Product Information
-
UV210
Sandvik UV210 is ideal for a wide range of crushing applications, and is particularly efficient with secondary and tertiary crushing. This equipment features Sandvik CV217 VSI impact crusher technology, which produces premium shaped aggregates and sand of a consistent high quality through controlled product grading. Although primarily designed for sand and aggregates, it is capable of processing a variety of material from hard and abrasive rocks to soft, moist or even sticky material.
Sandvik UV210 includes many advanced features enabling you to achieve maximum efficiency and reliability in your operation, whilst also helping to ensure operator safety with excellent stability and secure walkways. Service and maintenance is made simple, so your uptime can be kept at optimum levels.
Also available in the range is the Sandvik UV312 model.
-
Additional advantages
- Compact layout and excellent stability
- Security+ extended warranty & service package for higher uptime and peace of mind.
