Medium range breaker booms

BB7600H Breaker boom

Weight: 8,760.0 kg (19,312.0 lb)
Nominal horizontal reach: 6.4 m (21.0 ft)
Swing: 170 °

Sandvik BB7600H breaker boom is specially designed for mining markets to maintain optimum throughput, increase crusher efficiency and extend the life of the equipment.

Features

Over-dimensioned design

for better durability and reliability
Modular design

allows parts to be easily replaced
Conical Expander® pins

offer a long service life
Shock-absorbing pedestal mounting

makes the equipment stable under the toughest conditions and extends the foundation lifetime

Product data

Weight: 8,760.0 kg (19,312.0 lb)
Input power: 55 kW (74 hp)
Maximum reach: 9.000 m (29.500 ft)
Nominal horizontal reach: 6.4 m (21.0 ft)
Nominal vertical reach: 6.1 m (20.0 ft)
Swing: 170 °
Base dimensions: 1.52 x 1.22 m (4.98 x 4.00 ft)

Recommended breaker types BR2155i; BR2166i; BR2577i; BR3288i
Recommended power packs HU37; HU45; HU55

Additional product information

BB7600H

Easy maintenance and reliability of the BB7600H ensure you get the maximum uptime. The multi-fit pedestal design makes replacing existing, worn-out boom systems more convenient. The number of different parts is cut to a minimum by, e.g., fitting the same cylinders for all boom functions.
Durable and productive Sandvik BB7600H breaker boom provides a 9-meter maximum reach and 170-degree swing. Proven design combined with over dimensioning makes the boom a convenient and safe choice.
Additional advantages
- Sandvik full electrification makes the boom energy efficient
Applications
- Grizzlies
