Extra large range breaker booms

BB8102 Breaker boom

Weight: 15,500 kg (34,170 )
Nominal horizontal reach: 10.5 m (34.5 ft)
Swing: 170 °

Sandvik BB8102 breaker boom is versatile, and can be used in many applications, including grizzlies and gyratory crushers. The modular design means the equipment is easy to service, and parts can be replaced with minimal fuss, meaning less downtime overall.

Features

Heavy-duty design

reduces overall wear and lowers operating costs
High twist capacity

increases productivity
170° swing

offers optimal flexibility
Round pedestal

for even stress distribution

Product data

Weight: 15,500 kg (34,170 )
Input power: 55 kW (74 hp)
Maximum reach: 13.4 m (44.0 ft)
Nominal horizontal reach: 10.5 m (34.5 ft)
Nominal vertical reach: 10.0 m (32.8 ft)
Swing: 170 °
Base diameter: 2.29 m (7.50 ft)

Recommended breaker types BR2577i; BR3288i; BR4099i
Recommended power packs HU45; HU55

Additional product information

BB8102 breaker boom

Sandvik BB8102 breaker boom enables the hydraulic breaker to be optimally positioned and applied, allowing blockages or bridging of rock to be broken and cleared quickly and efficiently.
Durable and productive BB8102 provides a 13.4-meter maximum reach with a 170-degree swing for optimum flexibility. The boom is specially designed to maintain optimum crusher throughput, increase crusher efficiency and extend the life of the crusher.
Additional advantages
- Modular design allows parts to be easily replaced
- Heat-treated conical pins for extended service life
- Pedestal angle can be adjusted
- Sandvik full electrification makes the boom energy efficient
Applications
- Gyratory crushers
- Grizzlies
